Drinking water filtration equipment US-RO-1000I (2000L/hour)

Filtration equipment also varies, and one of them is water filtration equipment. This equipment is capable of filtering and processing 2000 liters of water per hour and is composed of parts with different functions: raw water pump, quartz sand filter, activated carbon filter, PP sediment filter and water softener. This equipment removes 98% of salt from water and 99% of total water. Their parameters are detailed in the description below.

	Basic parameters
	Filters
	Pump for water (raw)..................................................................................................	Voltage: 380V
		Power: 0.75 kW
		Pressure: 0.2 Mpa................................................................................
	Quartz sand filter (fiberglass)	Dimension: ⌀450*1650 mm
		Pressure: 0.2 Mpa
		Flow meter: 4m3/soat
		Flow speed: 15-18 m/soat
		Manganese: 250 kg
	Activated carbon filter (fiberglass)	Dimension: ⌀450*1650 mm
		Pressure: 0.2 Mpa
		Flow meter: 4m3/soat
		Flow speed: 15-18 m/soat
		Active carbon: 125 kg
	PP sediment filter (PVC-U)	Dimension: ⌀90*1000mm
		Flow: 4m3/soat
		Pressure: 0.2 Mpa
		1000 filter elements
	Water softener (fiberglass)	Dimension: ⌀450*1650 mm
		Flow: 8t/soat
		General hardness: 300 ppm (miqdori CaCO3 ga ko'ra)
		Cation: 100L

 An RO water system is also introduced and consists of different parts: RO membrane; multiphase pump; electric motor; flow measuring part; electromagnetic valve; stainless steel frame. The overall size of the equipment is 4800*700*2050 mm.
