Drinking water filtration equipment US-500L/hour (RO system)

Competing in quality with other filtration equipment, but lower in size and price, this water filtration equipment has a processing capacity of 500 liters of water per hour. Like its peers, it has multi-stage filters, namely quartz sand filter, activated carbon filter, PP sediment filter and water softener. This filter removes 98% of salt and harmful substances from water. Detailed information is reflected in the description below.



	Basic parameters
	Filters
	Pump for water (raw).....................................................................................................	Voltage: 380V
		Power: 0.75 kW
		Pressure: 0.2 Mpa...................................................................................
	Quartz sand filter (fiberglass)	Dimension: ⌀200*1000mm
		Pressure: 0.2 Mpa
		Flow meter: 2m3/soat
		Flow speed: 15-18 m/soat
		Quartz sands: 60 kg
	Activated carbon filter (fiberglass)	Dimension: ⌀200*1000 mm
		Pressure: 0.2 Mpa
		Flow meter: 2m3/soat
		Flow speed: 15-18 m/soat
		Active carbon: 30 kg
	PP sediment filter (UVC-U)	Dimension: ⌀90*1000mm
		Flow: 2m3/soat
		Pressure: 0.3 Mpa
		5U*1000 filter elements



An RO water system is also introduced and consists of different parts: RO membrane; multiphase pump; electric motor; flow measuring part; electromagnetic valve; stainless steel frame. The RO system removes 98-99% of salt from water, operates at 380V and has a power of 2.75 kW.
